Utility Trailer Kit // Trailer Kits // 2,000 lbs. Torsion Axle Trailer Kit

2,000 lbs. Torsion Axle Trailer Kit

Manufacturer: Trailer Kits
Part #: INTFLEXKIT2000
Quantity Discount% Discounted Base Price
2-4 3% $756.59
5-9 6% $733.19
10-29 9% $709.79
30-49 12% $686.39
50-500 15% $662.99
105 Years in Trailer parts Distribution
Free  FedEx  Ground Shipping and Volume Pricing

Drive Now & Pay Later - Select Pay Later at Checkout

2,000 lb. Dexter® Torflex® Torsion Axle trailer kit with thirteen-inch Allstar ST17580D13C white spoke wheel and tire, a 2" ball A-frame 50° RAM Coupler, and matching RAM A-Frame Jack.
Making selections in the following sections may change the final product price.
Outside of Brackets
Hub Face Measurement (Minimum Overall Overhang 13" Maximum Overall Overhang 21") (Example outside bracket 60" hub face will be 73" to 81") (Maximum 95" hub face)
CA-5100-B
CA-5210-B
CA-5196-B
CA-5196H-B
CT-2001-Z-CTN
CT-2002-Z-CTN
CT-2003-Z-CTN
CT-3001-Z-CTN
CT-3002-Z-CTN
CT-3003-Z-CTN
TJA-2001-B
TJB-2001-B
TJB-2001S-B
TJB-2002-B
TJB-2002S-B
TJP-5001-B
TJP-5001S-B
TJP-5002-B
TJP-5002S-B
MJ-1001-B
MJ-1200-B
MJ-1500-B
MJ-1500-DWL
SWWKIT201
SWWKIT202
SWWKIT203

Summary

  • Hub Face Measurement (Minimum Overall Overhang 13" Maximum Overall Overhang 21") (Example outside bracket 60" hub face will be 73" to 81") (Maximum 95" hub face)
  • 22.5° Down - No Load H 3.52" L 5.54" Full Load H 1.22" L 6.00" Shock Load H 0.05" L 5.88"
  • Cambered, Brake Flange, E-Z Lube Spindle, Low Profile Mounting Bracket in Standard Orientation, No Pre-Wire, Painted
  • By selecting this box, you agree this is a custom-built to order Torflex trailer axle to the specifications provided on this order form. Once the order is placed the axle cannot be altered, changed, cancelled, or returned for any reason. If you have any questions before placing this order please email [email protected] or call 1-800-866-3336
  • 2" ball 5,000 lbs. capacity 50 degree stamped a-frame top latch coupler (standard)
  • 2,000 Topwind RAM A-Frame Jack (standard)
  • One Diode LED Kit Square for Single Axle Trailer (standard)
$779.99
$779.99

Description

You have selected the 2,000 lb. Dexter® Torflex® Torsion Axle trailer kit with thirteen-inch Allstar ST17580D13C white spoke wheel and tire, a 2" ball A-frame 50° RAM Coupler, and matching RAM A-Frame Jack.  We have many different lengths of axles for your trailer.  We ask that you provide your desired outside frame width, hub face, and starting angle of your torsion axle when placing your order.  Below is a complete bill of materials for the trailer kit you have selected.

Bill of materials for selected 2,000 lb. trailer kit:

  • (1) 2,000 lb. Dexter® Torflex® Torsion Axle with 5-4.5" hubs (Some assembly required)

  • (2) Thirteen-inch Allstar ST17580D13C white spoke wheels and tires

  • (2) Thirteen-inch fenders

  • (1) Optronic's One Diode LED Trailer light kit including taillights, clearance lights, license plate bracket, and wire harness

  • (1) RAM 2" 50° A-frame coupler

  • (1) RAM A-frame jack

  • (2) Safety chains with weld on brackets

Part Number: INTFLEXKIT2000 | Total weight: 300 lb.
